Apical root resorption: classification, diagnostic approach, therapeutic management

Introduction

Apical root resorption in permanent teeth is a pathological condition characterized by the loss of root substance as a result of the action of osteoclasts and immune cells, in response to factors such as bacterial infection, trauma, and chemical or physical agents that irritate or injure the periodontal ligament and the dental pulp (1,2,3). In contrast, in primary teeth, it is a desirable physiological process that allows the atraumatic eruption of their permanent successors. The morphology of the apical root area is decisive for determining the biologically acceptable point at which the working length and the obturation of the root canal should be established. According to the literature, the point at which chemomechanical preparation should be completed is the apical constriction, which terminates at the apical foramen, whose position does not always coincide with the anatomical apex (4).

Deviations in the morphology of the apical region have great clinical significance because they affect the ability to achieve a hermetic seal. It is evident that, in cases where apical resorption is also present, the morphology of the apex resulting from the resorptive processes negatively influences the clinician’s ability to obturate the root canal. Resorption may destroy the apical constriction and compromise the retention of obturation materials and irrigating solutions within the root canal. Therefore, for treatment purposes, the clinician must be aware of and able to manage such conditions. The categories of resorption indicate its etiology, location, and morphology. The most widely used classification of apical resorption is Andreasen’s. Each type of resorption has its own clinical and histopathological characteristics, as well as characteristic causative factors and management approaches, in addition to its frequency of occurrence—elements that will be analysed in the present article.

Classification and etiology of apical resorption

Apical resorption constitutes a pathological process of degradation of the mineralized dental tissues, which is activated following injury or inflammation of the periodontal ligament and the protective layer of cementoblasts and the epithelial rests of Malassez (5,6). When these tissues become irritated, a chemotactic process leads to the accumulation of osteoclasts, which initiate resorption. Osteoclasts are located between the periodontal ligament and the cementum, residing in Howship’s lacunae (6). Although multiple classifications have been proposed, Andreasen was the first to introduce a clear functional framework, distinguishing resorption into internal (inflammatory and replacement) and external (surface, inflammatory, and replacement) categories (1).

Subsequent authors, such as Gartner et al. (7), Tronstad (2), and Trope (8), maintained the same basic distinction, while modifying specific subcategories based on location or etiology. Heithersay (9), Patel (10), and Darcey & Qualtrough (11) expanded this perspective by adding forms such as cervical or transient resorption.

Finally, Kanas and Kanas (12) proposed the most comprehensive and contemporary classification, incorporating parameters of dental and non-dental etiology (traumatic, inflammatory, idiopathic, orthodontic, or systemic).

Despite the evolution of classification systems, Andreasen’s approach (1) remains the most widely used, as it establishes the fundamental distinction between internal and external resorption, upon which subsequent frameworks are based. External inflammatory resorption comprises the following subcategories: cervical resorption, with or without pulpal involvement, and apical resorption, which is primarily associated with pulpal infection (13, 14, 15).

However, apical resorption may also be associated with non-microbial causes, such as orthodontic tooth movement, in which aseptic inflammation is observed. Additionally, certain types of dental trauma, such as avulsion and intrusion, also appear to contribute to resorption of the apical portion, as the violent injury to the periodontal ligament can induce external replacement resorption.

Prevalence of different types of resorptions

Bates first described the concept of apical resorption in 1856, associating it with trauma to the periodontal membrane (16). Ketcham (1927, 1929) studied 500 patients after orthodontic treatment and found resorption in 21%, while in untreated individuals the rate was 1% (17, 18). Rudolph (1936) reported a prevalence of up to 74%, which in a later study of his reached 100%. In a control sample without orthodontic treatment, he found only 5% (19, 20). In 1947, at the University of Illinois, histological analysis of 261 teeth showed resorption in 90.5% of cases (21). Massler and Malonea (1954), in a sample of 708 individuals, recorded 86.4% with resorption, 1.6% with no lesions at all, and 81.2% idiopathic cases (22).

Sex-related differences have been inconsistently reported: some studies found a higher prevalence in females (23), while others reported no statistically significant association with gender (24). The prevalence increases with age (1, 2). Resorption is most frequently located at the apex (22) and in maxillary teeth (25), although opposing findings have also been reported (26). Molars are most affected (27), while other studies report central incisors due to their susceptibility to trauma (18, 28, 29). External apical resorption accounts for 95.2% of cases, whereas internal resorption accounts for 4.8%. The external inflammatory form appears in 58.04%, with pulpal infection being the main cause (71.2%) (30), although others do not confirm this association (31).

According to the University of Illinois, inflammation does not always cause resorption, as no defects were observed in the cervical third despite the presence of periodontal inflammation. External inflammatory resorption is also associated with trauma, occurring in 18% of cases after partial avulsion and in 30% after replantation (1, 30). Replacement resorption was found mostly in molars (0–15.04%) (30), and more frequently after complete avulsion (87.2%), intrusion (57.1%), lateral displacement (35.5%), or vertical displacement (4.8%) (1). The type of resorption is related to the type of tooth: in second molars, replacement resorption is more prevalent, whereas in first molars, external inflammatory resorption predominates (30). External cervical resorption is recorded at 22.12%, while periodontal-related resorption is at 3.9%, increasing with reduced bone support, deeper pockets, and greater tooth loss. Idiopathic resorption occurs mainly in young individuals (mean age 23 years) and accounts for 4.42% of cases, mostly in maxillary canines (26).

However, the limitations of these studies must be noted. Few studies analyse the prevalence of each type of resorption separately, while most rely on panoramic radiographs, which underestimate lesion extent. In studies using CBCT or histological analysis, the reported rates are significantly higher (32). Moreover, there is no universally accepted severity scale or standardized criteria for what constitutes pathological resorption, making comparisons between older and more recent data difficult. Finally, classification and etiological associations vary among authors, leading to variable and often non-comparable results (33, 34).

Diagnosis

The diagnosis of resorption is usually an incidental radiographic finding and is difficult, as the affected teeth are often asymptomatic (35). The most common diagnostic method is panoramic radiography, either alone or in combination with periapical imaging, primarily to overcome diagnostic difficulties in the anterior region (36). In their study, Sameshima and Asgarifar, comparing panoramic radiographs with periapical images as a diagnostic tool, found that panoramic imaging overestimates resorption and root shortening by more than 20% (37). However, imaging with the paralleling technique, as reported by Remington et al., cannot accurately measure root lengths (38). Furthermore, although it has high diagnostic value, it is geometrically inaccurate (39).

To investigate the morphology and extent of resorption on all root surfaces, the MBD method proposed by Gartner et al. is often used, which involves taking two radiographs—one perpendicular to the root and the other with mesial angulation (7). The different imaging angles help identify the surfaces involved and allow proper classification of the lesion. Nevertheless, in their study, Creanga et al. observed slightly better diagnostic outcomes (40) using only perpendicular projections compared with angled projections. The available literature, however, is limited, as all studies comparing two-dimensional with three-dimensional imaging treat periapical radiography as a single modality regardless of the angle at which it is taken (40).

The above study agrees that the most reliable diagnostic method for resorption is three-dimensional imaging. CBCT imaging is a more sensitive technique, although its reported sensitivity is 69% (41).

The specificity of the method using different angulations of conventional periapical radiographs and CBCT was found to be above 79%, with that of CBCT reaching 91% (40).

Patel et al. support the use of cone-beam computed tomography, as it appears to have greater diagnostic value—something that is now also recommended by the European Society of Endodontology (32).

Chapnick reports that small apical resorptive defects are more difficult to diagnose (42). For this reason, Heo proposes digital subtraction radiography for the detection of small resorptions (43), although Levander demonstrated that digital techniques were comparable to conventional film-based methods (44). In their study, Chan and Darendeliler found that after 28 days of orthodontic force application, the diagnostic value of CBCT and periapical radiographs was comparable. However, they report that after a longer period, when resorptive areas become larger, periapical radiographs may be insufficient for evaluating resorption (45).

In the studies by Darcey and Qualtrough (11), the clinical and radiographic characteristics of the various types of resorptions are described. The presentation of signs and symptoms must be framed within an accepted classification system. The classification we will use is that of Darcey and Qualtrough, one of the most contemporary and closely aligned with that of Andreasen, which is the most widely used and generally accepted, an advantage when synthesizing the literature. Specifically, they describe internal replacement and internal inflammatory resorption, which may progress and lead to root perforation. They then distinguish the external resorptions caused by periodontal damage, subdivided into surface, inflammatory, replacement (which leads to ankylosis), cervical, and apical resorption. For each type of resorption, the authors provide radiographic diagnostic features.

Regarding external apical resorption, in two-dimensional imaging, it appears as shortening and rounding of the apex with well-defined margins and the presence or absence of a periapical lesion, depending on whether an inflammatory cause is present. The root canal remains clearly visible and continuous. In three-dimensional imaging (CBCT), the authors describe asymmetry at the apex, conical loss of tooth structure, or a crater-like defect, with or without bone involvement, depending on the presence of an inflammatory etiology. When the cause is orthodontic treatment, multiple teeth are symmetrically affected.

Management of apical resorption

Non-inflammatory apical resorption

It is mainly caused by orthodontic treatment (3, 38, 46). If resorption is diagnosed during treatment, the magnitude of the applied forces is reduced, although this does not guarantee cessation of the resorption process; alternatively, orthodontic treatment is discontinued for approximately 3–6 months, allowing osteoclastic activity to subside (47, 48). If the diagnosis is made after completion of orthodontic treatment, regular follow-up and radiographic evaluation every 6–12 months are recommended (49) to confirm that resorption has not continued. Endodontic treatment is not required unless pulp necrosis occurs. Overall, the prognosis is excellent, especially when the resorption is small (<2 mm) (2, 33). (Figure 1)

External inflammatory apical resorption

It is caused by a microbial stimulus, namely, pulpal infection. The goal is to eliminate this microbial irritation. In permanent teeth with a closed apex, treatment includes endodontic therapy with chemomechanical preparation using sodium hypochlorite and EDTA, followed by placement of calcium hydroxide paste inside the canal for 2–3 weeks (14, 48, 50). Final root canal treatment is performed when radiographic signs of inflammation subside.

The management of necrotic permanent teeth with an open apex represents one of the greatest challenges in endodontic therapy due to incomplete root development and increased fragility of the canal walls (14). Regenerative endodontics has emerged as an innovative treatment approach, aiming to revascularize and regenerate pulp tissue (50), allowing continued root development and strengthening the tooth’s structural integrity (51). Its success depends on strict case-selection criteria, such as patient age (6–17 years), presence of an open apex (>1.1 mm), the ability to induce bleeding, and the absence of systemic factors that impair healing (52).

When these criteria are not met, or canal disinfection is not achievable, apexification using calcium hydroxide, MTA, or bioceramic materials remains the preferred option, offering high success rates (>90%) without promoting further root development (53, 54).

Additionally, biological techniques such as PRP (Platelet-Rich Plasma) and PRF (Platelet-Rich Fibrin) have shown promising results, as their growth factors enhance tissue regeneration and restoration of apical morphology (55, 56). According to Peter E. Murray (2022), PRP/PRF techniques outperform simple blood-clot revascularization (BCR) in achieving apical closure, periapical healing, and root elongation. However, their outcomes remain unpredictable, and for this reason, they are not widely adopted in the scientific community (57).

Therefore, the selection of the appropriate treatment must be based on differential diagnostic criteria that take into account: root maturity, pulp status, patient health and cooperation, and the clinician’s capabilities. In addition, several studies have examined pharmaceutical agents such as doxycycline, acetazolamide (58), ascorbic acid, and alendronate for the prevention or management of inflammatory resorption (59, 60, 61), but not for replacement resorption. Ledermix, which contains corticosteroids and antibiotics, has been shown to prevent inflammatory resorption, while Emdogain (62, 63) may contribute to periodontal healing, although its efficacy against ankylosis remains controversial. It should be noted that most of these studies involve replanted teeth and were conducted on animal models, limiting the generalizability of the results to humans (60, 62, 64). (Figures 2–4)

Apical resorption of traumatic etiology

According to Andreasen (1), following lateral luxation injury or avulsion, 78% of teeth will develop replacement resorption and become ankylosed. This occurs mainly in fully formed apices (33). It is not related to microorganisms within the pulp and is a hormone-dependent process. In such cases, the lesion cannot be halted. When dentin loss exceeds 20%, ankylosis develops. The prognosis is poor, and the tooth will eventually be lost over time.

The term transient apical resorption also appears in the literature. This entity is observed in 23% of cases at 3 months and in 86% at 1 year after trauma. Radiographically, it appears as root shortening or blunting and is often misdiagnosed by clinicians as inflammatory resorption. In reality, it is an organismic healing process; therefore, periodic monitoring is recommended, especially if the patient exhibits no other symptoms. (Figure 5)

Discussion

Apical root resorption is a multifactorial process influenced by mechanical, microbial, and traumatic stimuli. The literature review highlights considerable discrepancies in reported prevalence, largely due to heterogeneity in study design and imaging modalities. Older studies based on panoramic radiographs underestimate the extent of lesions, whereas CBCT and histological analyses reveal substantially higher rates, underscoring the need for standardized diagnostic criteria.

Although Andreasen’s classification remains the most widely accepted, it does not fully encompass the spectrum of clinical presentations. More recent systems aim to integrate etiological and morphological parameters, yet universal adoption remains limited, limiting the comparability of findings across studies. Therapeutically, regenerative endodontics and adjunctive pharmacological agents show promise, but their predictability and long-term outcomes remain uncertain, restricting routine clinical use. Overall, early diagnosis and accurate etiological assessment remain the most decisive factors for successful management.

Conclusions

Apical resorption is caused by various factors, such as bacterial infection, orthodontic treatment, trauma, and chemical agents, affecting the periodontal ligament and the pulp. Several categories of resorption exist, distinguished according to etiology and location.

The prevalence of resorption varies by population and clinical conditions, with external inflammatory resorption being the most common form.

Diagnosis is primarily achieved through radiographic methods, with CBCT providing the highest diagnostic accuracy, particularly for small lesions.

Depending on the type and cause of resorption, treatment may include conservative endodontic procedures, localized removal of resorptive defects with specialized materials (e.g., glass ionomers or bioceramics), or tooth extraction (65).

Accurate classification of resorption is crucial for distinguishing between different pathological conditions and selecting the appropriate treatment.

Regenerative endodontics using stem cells, growth factors, and scaffolds (PRP, PRF) may enhance healing and regeneration of the apical area, providing an alternative approach for necrotic teeth with immature apices.

Future Directions

1. Unified Classification System
2. Targeted Biomaterials and Pharmacologic Agents
3. Genetic and Systemic Risk Factors
4. Artificial Intelligence in Detection
